30 Inch Vertical Self-Luminous OLED LG Transparent Screen TV Advertising Display with P-Cap Touch
Premium Transparent OLED Display for Interactive Commercial Signage
The 30 Inch Vertical Self-Luminous OLED LG Transparent Screen TV Advertising Display with P-Cap Touch is a high-end compact digital signage solution designed for luxury retail stores, museums, exhibitions, smart kiosks, and corporate reception areas. It uses advanced transparent OLED display technology to deliver a futuristic transparent OLED screen experience where digital content appears to float in space while still allowing viewers to clearly see objects placed behind the display.
As a professional OLED display manufacturer, this product is designed for modern transparent digital signage applications that combine interactivity, premium design, and immersive visual storytelling.
LG Transparent OLED Screen with Self-Emissive Technology
Floating Visual Experience with High Transparency
This transparent OLED screen is based on self-emissive OLED technology, meaning each pixel generates its own light without a backlight layer. This enables ultra-thin structure, high contrast, and vivid color performance while maintaining a see-through visual effect.
Based on LG transparent OLED commercial panel standards, typical characteristics include:
- 30-inch LG transparent OLED panel
- HD resolution (1366 × 768)
- Approx. 37% transparency level
- Wide 178° viewing angle
- High contrast with self-emissive pixels
- 10-point capacitive P-Cap touch support
- Ultra-slim glass structure design
- Smooth motion video playback
This creates a “floating content” effect that significantly improves engagement in retail and exhibition environments.
| 30-inch vertical transparent kiosk(ZXTLCD-OLED300V) |
| LCD Panel Parameters |
| Screen Size |
30 inch |
| Panel type |
Transparent OLED |
| Resolution |
768*1366 |
| Brightness |
200-600cd/㎡ Automatic adjustment |
| Contrast Ratio |
135000:1 |
| Viewing angle(up/down/left/right) |
178°(H)/178°(V) |
| Response Time |
0.1ms(Gray To Gray) |
| Display color |
10bit(R),1.07 billon colors |
| Onboard interface |
| Input Interface |
HDMI*1,DP*1,RS232 |
| Output interface |
RS232 |
| Touch Method |
| Capacitive Touch screen |
Default 10 points Capacitive Touch |
| Power Specifications |
| Power supply |
AC 100-240V |
| Total System Power Consumption |
<280W |
| Machine Operating Parameters |
| running time |
7*12h |
| Screen life |
30000h |
| Operating temperature |
0℃~40℃ |
| Operating Humidity |
20%~80% |
| structure |
| Material |
Aluminum+Tempered Glass+Metal |
| external dimensions |
TBD |
| Overall dimensions |
TBD |
| Installation Method |
Base installation |
| Net weight / Gross weight |
TBD |
| Accessories |
| Power cord, HDMI port, USB port, remote control, certificate of conformity and warranty card, instruction manual |
| other |
| After-Sales Service |
1-Year Warranty |
Vertical Design for Smart Interactive Applications
Space-Efficient Premium Display Structure
The vertical design makes this transparent OLED screen ideal for close-range interaction and high-traffic commercial areas.
Key advantages include:
- Vertical orientation for eye-level engagement
- Compact footprint for retail counters
- Modern frameless glass aesthetic
- Ideal for product storytelling and branding
- Suitable for continuous commercial operation
It is especially effective for environments requiring both visibility and digital interaction.
Applications of Transparent Digital Signage
The 30-inch LG transparent OLED touch display is widely used in:
- Luxury retail product showcases
- Jewelry and cosmetics display counters
- Museum interactive exhibits
- Exhibition and trade show booths
- Smart information kiosks
- Corporate reception desks
- High-end brand storytelling systems
- Technology demonstration zones
Its transparency allows physical products to remain visible while digital content enhances presentation.
FAQ
What is a transparent OLED display?
A transparent OLED display is a self-emissive screen that allows users to see through it while displaying digital content.
What is the advantage of LG transparent OLED technology?
It provides high transparency, vivid colors, and interactive touch capability in a compact commercial format.
Does it support touch interaction?
Yes, it supports 10-point capacitive P-Cap touch input.
Where is it commonly used?
It is widely used in retail, museums, exhibitions, and smart commercial environments.
Conclusion
The 30 Inch Vertical Self-Luminous OLED LG Transparent Screen TV Advertising Display with P-Cap Touch combines LG-grade display performance, interactive touch capability, and advanced transparent OLED display technology. As a professional OLED display manufacturer, it delivers high-impact transparent OLED screen and transparent digital signage solutions that enhance engagement, branding, and immersive customer experiences.
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
